Supports Intel® Xeon® 6th Gen 6700P/6700E-series processors
•
NVIDIA HGX B300 8-GPU with NVSwitch
•
8 x OSFP 800 Gbps Infiniband Ports
•
Supports 16+16 DDR5 RDIMM Expandable Memory
•
4 x16 PCIe 5.0 Expansion Slots
•
Latest AST2600 BMC Controller iKVM, vMedia support
•
Support 12 x 2.5" Hot Swappable Bays
•
Dual 1GbE(RJ45) via Intel i350-AM2
•
(6 + 6) 3000W 80+ Redundant Titanium Power Supply
Processor/Cache
Processor
Supports Dual Intel® Xeon® 6th Gen 6700P/6700E series Processors of upto 350W TDP (LGA 4710)
System Memory
Memory Capacity
Supports 16+16 DDR5 RDIMM Expandable Memory Max 6400 MT/s (1DPC) / 5200 MT/s (2DPC) Frequency (Depends Upon CPU SKU) Max Capacity RDIMM-3DS : 256GB/DIMM, Max System Memory 8TB
Expansion Slots
PCI-Express
4 x16 PCIe 5.0 FHHL single width slots
Drive bays
Drive bays
Supports 12 x 2.5" NVMe Hot Swappable drive Bays Supports 1 x M.2 PCIe x2 Internal Drives
I/O Ports
I/O Ports
2 x RJ45 1G Base-T via Intel i350-AM2 (Front) *Same can be accessible from Rear Side as well 1 x RJ45 dedicated IPMI 2.0 LAN port (Front) *Same can be accessible from Rear Side as well 1 x VGA DB15 Port (Front) 4 x USB 3.0 Type A (Front) 2 x USB 3.0 Type A (Rear) 1 x VGA DB15 Port (Rear)
Front LEDs
Front LEDs
1 x Power button/LED (Front) 1 x Reset button (Front) 1 x UID button (Front/Rear) 1 x System Fault LED (Front) 12 x HDD LEDs (Front)
Specifications subject to change without notice. Picture used for representation purpose only and the actual product may differ in looks All other brands and names are the property of their respective owners
